型 号 | Model | YG-G1 |
电 源 | Power | AC220V 50/60 Hz 单相 AC220V 50/60 Hz single-phase |
功 能 | Function | 电线切断、单端剥皮、双端剥皮、单端压着、单端扭线、单端半剥 Wire cutting, single-end stripping, both-end stripping, single-end pressing, single-end twisting, and single-end half-stripping |
产 能 | Productivity | 不扭线4800 条 / 小时、扭线3500条/小时(300mm以内) No twisting: 4800 pieces/hour; twisting: 3500 pieces/hour (within 300mm) |
电线规格 | Wire specification | AWG32 -- AWG18 |
剥皮长度 | Stripping length | 0.5mm-13mm |
加工长度 | Processing length | 19mm -- 9999mm(指中间留皮部分refer to the middle part with skin) |
切断精度 | Cutting precision | 误差少于1mm(设定长度x0.002)可修正 The error less than 1mm (set length x 0.002) can be corrected. |
扭线长度 | Twisting length | 3mm--20mm |
空气压力 | Air pressure | 5--8kgf(需使用清洁干燥空气) 5-8kgf (need clean and dry air) |
检测装置 | Testing equipment | 入线异常、气压不足、冲模不良、端子有无、未打端、未剥皮 Abnormal entering, insufficient pressure, unsound punching, no terminal, no ending, and no stripping |
压着能力 | Pressing capacity | 2.0 tons |
外观尺寸 | External dimensions | 680W x 850L x 1250H mm |
重量 | Weight | 320kg |
